Incineration perfectly fits into a trend of treating waste in a safe way, and if possible, at the
※Main Feature:
–Three Combustion Chambers or A/B Primary Combustion Chamber
— Double or Three Italy Burner
–Burning Rate: 80-800kgs per hour
–Combustion Chamber: 1.0M3-10.0M3
※Optional Function/Parts/Material/Burning Rate:
— Stainless Steel Chimney
— Dry Smoke Filter Chamber
— Chimney Height Custom Made
— Semi-Automatic Waste Feeding
— 3-Section Wet Scrubber System
— Movable Platform Feeding Door
— Additional Burner
Tel: +86-25-8461 0201
Website: www.hiclover.com
Email: [email protected]
Email: [email protected]
| Items/Model | TS10(PLC) | TS20(PLC) | TS30(PLC) | TS50(PLC) | TS100(PLC) |
| Burn Rate (Average) | 10 kg/hour | 20 kg/hour | 30 kg/hour | 50 kg/hour | 100 kg/hour |
| Feed Capacity(Average) | 20kg | 40kg | 60kg | 100kg | 200 kg |
| Control Mode | PLC | PLC | PLC | PLC | PLC |
| Combustion Chamber | 100L | 210L | 330L | 560L | 1200L |
| Internal Dimensions | 50x50x40cm | 65x65x50cm | 75x75x60cm | 100x80x70cm | 120x100x100cm |
| Secondary Chamber | 50L | 110L | 180L | 280L | 600L |
| Smoke Filter Chamber | Yes | Yes | Yes | Yes | Yes |
| Feed Mode | Manual | Manual | Manual | Manual | Manual |
| Voltage | 220V | 220V | 220V | 220V | 220V |
| Power | 0.5Kw | 0.5Kw | 0.5Kw | 0.7Kw | 0.7Kw |
| Oil Consumption (kg/hour) | 5.4–12.6 | 7.8–16.3 | 10.2–20 | 12.1–24 | 14–28 |
| Gas Consumption (m3/hour) | 6.2–11.4 | 8–15.7 | 9.8–20 | 9.9–26.1 | 10–32.2 |
| Temperature Monitor | Yes | Yes | Yes | Yes | Yes |
| Temperature Protection | Yes | Yes | Yes | Yes | Yes |
| Oil Tank | 100L | 100L | 100L | 100L | 200L |
| Feed Door | 30x30cm | 45x40cm | 55x50cm | 70x55cm | 80x60cm |
| Chimney | 3Meter | 3Meter | 5Meter | 5Meter | 10Meter |
| Chimney Type | Stainless Steel | Stainless Steel | Stainless Steel | Stainless Steel | Stainless Steel |
| 1st. Chamber Temperature | 800℃–1000℃ | 800℃–1000℃ | 800℃–1000℃ | 800℃–1000℃ | 800℃–1000℃ |
| 2nd. Chamber Temperature | 1000℃-1200℃ | 1000℃-1200℃ | 1000℃-1200℃ | 1000℃-1200℃ | 1000℃-1200℃ |
| Residency Time | 2.0 Sec. | 2.0 Sec. | 2.0 Sec. | 2.0 Sec. | 2.0 Sec. |
| Gross Weight | 1500kg | 2200kg | 3000kg | 4500kg | 6000kg |
| External Dimensions | 140x90x120cm | 160x110x130cm | 175x120x140cm | 230x130x155cm | 260x150x180cm |
Unit purpose Infected medical waste decontamination
Unit made from stainless steel Necessary
Decontamination process is conducted in a closed system Necessary
Waste shredding within sterilization process Necessary
Decontamination method 1No pressure;
2Moisture and heat.
Microbiological decontamination level At least 6 log10
Sterilization cycle temperature At least 1400C
The sterilization cycle time Not more than 40 min.
One cycle treated waste volume At least 100 litrų
One cycle treated waste weight At least 7 kg
Decontaminated waste must be 1Dry,
2Odorless,
3Not identifiable
The waste volume reduction after treatment At least 70%
The waste weight reduction after treatment At least 30 %
Unit control Microprocessor
Control panel Digital with touch screen
Noise level At least 80 dB
Power consumption Not more than 0,5 kWh/kg
Water consumption Not more than 0,003 m3/kg
Filtering system 1At least two-stage carbon filters;
2HEPA filter.
HEPA efficiency At least 95%
Unit capacity At least 15 kg/hr.
Impact on the environment and workers Safe, environmentally friendly
Dimensions (for particular room) 90 width (±10) x 150 depth (±10) x
120 height (±10)
