Solid/ Domestic Waste Incinerator
Waste Type: Domestic Waste
Average Emissions Rates: Not to exceed EU Standard Limits (Total dust “mg/m3”: 30;
The primary combustion chamber is the main structure of the incinerator, fabricated from mild
Waste Type: Domestic Waste
Average Emissions Rates: Not to exceed EU Standard Limits (Total dust “mg/m3”: 30;
Sulphur Dioxide: 200; Nitrogen Dioxide: 400; Carbon Monoxide: 100)
Minimum Burn Rate: 2,000 kg per day (up to 1,500-person camp); top loading
Insulation: high-grade fireproof insulation backing.
Loading/Ash removal: Manual loading and ash removal from side door or tray.
External Finish: high-temperature coat
Controls: Fully automatic control through PLC system for burn chamber temperature; burn and cool down cycles
Operational Temperature: 850-13300C
Burner/s: Fully automatic, high-efficiency burners with electronic ignition, flame recognition
Minimum Burn Rate: 2,000 kg per day (up to 1,500-person camp); top loading
Insulation: high-grade fireproof insulation backing.
Loading/Ash removal: Manual loading and ash removal from side door or tray.
External Finish: high-temperature coat
Controls: Fully automatic control through PLC system for burn chamber temperature; burn and cool down cycles
Operational Temperature: 850-13300C
Burner/s: Fully automatic, high-efficiency burners with electronic ignition, flame recognition
sensors with combustion control features; Burner Fuel: Diesel; Electrical supply:
Single, 220-240V; or 3-phase, 380-415V, 50-60Hz
Complete kit with chimney, filters (if applicable) and 2 years spare parts.
Manufacturer specification and technical datasheet shall be provided.
all be provided.
Complete kit with chimney, filters (if applicable) and 2 years spare parts.
Manufacturer specification and technical datasheet shall be provided.
all be provided.
The primary combustion chamber is the main structure of the incinerator, fabricated from mild
steel plate and stiffened with rolled steel sections. It is carried from the floor level on a substantial
steel support frame. Internally the shell is lined with calcium silicate insulation and a hot
face combination of super duty brickwork or high strength castable.
The primary combustion chamber must ensure minimum exit temperature is not less than 850°C.
One Manual Load Incinerator comprising:
Manual Loading door
Horizontal solid hearth, refractory lined primary combustion chamber. Approximate
The primary combustion chamber must ensure minimum exit temperature is not less than 850°C.
One Manual Load Incinerator comprising:
Manual Loading door
Horizontal solid hearth, refractory lined primary combustion chamber. Approximate
dimensions 800 mm diameters x 2100mm long
Full sized bulk load/ash removal door
1 off diesel-fired ignition burner ― temperature controlled
1 off combustion air supply fan and distribution system, automatic control
High capacity secondary combustion chamber with residence time not less than 2 seconds @ >850°C
1 off diesel-fired afterburner ― temperature controlled
Control panel ― automatic operation
Temperature indication primary and secondary chambers 0-1200°C
Refractory lined flanged chimney to a height of 10M above ground level
Fully packaged oil type, complete with electric ignition and flame failure controls wired
Full sized bulk load/ash removal door
1 off diesel-fired ignition burner ― temperature controlled
1 off combustion air supply fan and distribution system, automatic control
High capacity secondary combustion chamber with residence time not less than 2 seconds @ >850°C
1 off diesel-fired afterburner ― temperature controlled
Control panel ― automatic operation
Temperature indication primary and secondary chambers 0-1200°C
Refractory lined flanged chimney to a height of 10M above ground level
Fully packaged oil type, complete with electric ignition and flame failure controls wired
with continuous running fan and complete with all valves, fan and motor.
Maximum rating: at least 450kW/hour
Burner: arranged for on/off operation
Maximum consumption: at least 9 litres/hour
Maximum rating: at least 450kW/hour
Burner: arranged for on/off operation
Maximum consumption: at least 9 litres/hour
Average consumption: at least 4.5 litres/hour
Nanjing Clover Medical Technology Co.,Ltd.
Tel: +86-25-8461 0201
Mobile: +86-13813931455(whatsapp/wechat)
Website: www.hiclover.com
Email: [email protected]
Email: [email protected]
Website: www.hiclover.com
Email: [email protected]
Email: [email protected]
| Items/Model | TS10(PLC) | TS20(PLC) | TS30(PLC) | TS50(PLC) | TS100(PLC) |
| Burn Rate (Average) | 10 kg/hour | 20 kg/hour | 30 kg/hour | 50 kg/hour | 100 kg/hour |
| Feed Capacity(Average) | 20kg | 40kg | 60kg | 100kg | 200 kg |
| Control Mode | PLC | PLC | PLC | PLC | PLC |
| Combustion Chamber | 100L | 210L | 330L | 560L | 1200L |
| Internal Dimensions | 50x50x40cm | 65x65x50cm | 75x75x60cm | 100x80x70cm | 120x100x100cm |
| Secondary Chamber | 50L | 110L | 180L | 280L | 600L |
| Smoke Filter Chamber | Yes | Yes | Yes | Yes | Yes |
| Feed Mode | Manual | Manual | Manual | Manual | Manual |
| Voltage | 220V | 220V | 220V | 220V | 220V |
| Power | 0.5Kw | 0.5Kw | 0.5Kw | 0.7Kw | 0.7Kw |
| Oil Consumption (kg/hour) | 5.4–12.6 | 7.8–16.3 | 10.2–20 | 12.1–24 | 14–28 |
| Gas Consumption (m3/hour) | 6.2–11.4 | 8–15.7 | 9.8–20 | 9.9–26.1 | 10–32.2 |
| Temperature Monitor | Yes | Yes | Yes | Yes | Yes |
| Temperature Protection | Yes | Yes | Yes | Yes | Yes |
| Oil Tank | 100L | 100L | 100L | 100L | 200L |
| Feed Door | 30x30cm | 45x40cm | 55x50cm | 70x55cm | 80x60cm |
| Chimney | 3Meter | 3Meter | 5Meter | 5Meter | 10Meter |
| Chimney Type | Stainless Steel | Stainless Steel | Stainless Steel | Stainless Steel | Stainless Steel |
| 1st. Chamber Temperature | 800℃–1000℃ | 800℃–1000℃ | 800℃–1000℃ | 800℃–1000℃ | 800℃–1000℃ |
| 2nd. Chamber Temperature | 1000℃-1200℃ | 1000℃-1200℃ | 1000℃-1200℃ | 1000℃-1200℃ | 1000℃-1200℃ |
| Residency Time | 2.0 Sec. | 2.0 Sec. | 2.0 Sec. | 2.0 Sec. | 2.0 Sec. |
| Gross Weight | 1500kg | 2200kg | 3000kg | 4500kg | 6000kg |
| External Dimensions | 140x90x120cm | 160x110x130cm | 175x120x140cm | 230x130x155cm | 260x150x180cm |
