Model |
CA100 |
|
Picture |
|
|
Waste Treatment |
Medical Waste Incineration Treatment |
|
Feed Capacity |
Average 100-200 kgs per feed |
|
Burning Rate |
Average 100-120 kgs per hour |
|
Burning Time per Feed |
Average 1-2 hour |
|
Control Mode |
PLC(Programmable Logic Controller Incinerator) |
|
Voltage |
220V |
|
Power |
1.0Kw |
|
Fuel |
Diesel oil |
|
Burner |
|
|
Feed Mode |
Manual |
|
Temperature Monitor |
Digital Display |
|
Fuel consumption (Oil) |
Average 20.4 Kgs/Hour |
|
Internal Dimensions |
100x80x |
|
External Dimensions |
230 x 130 x |
|
Waste combustion chamber |
560Liters |
|
Post Combustion Chamber |
280Liters |
|
Oil Tank Capacity |
200 Liters |
|
Door Opening |
70 x |
|
Chimney |
|
|
Gross Weight |
4500kgs |
|
Chamber Material |
Firebrick ,Refractory Concrete |
|
Max. Heat Value |
166,000Kcal/Hr. |
|
Operation Technical Specifications |
|
|
Solid Chamber temperature |
|
|
Gas Chamber temperature |
|
|
Chamber Anti-Rate |
|
|
Residency time |
2.0 Sec. |
|
Burning efficiency |
＞98% |
|
Waste Lower Calorific Power |
3000Kcal |
