MEDIUM-CAPACITY ANIMAL CARCASS INCINERATOR HICLOVER Model TS100(PLC)

MEDIUM-CAPACITY ANIMAL CARCASS INCINERATOR HICLOVER Model TS100(PLC) with wet scrubber optional

Items/Model

TS100(PLC)




Principle

Waste Incineration Treatment(Poultry and dead fish

Incinerator Machine)

Burn Rate

Average 50-100 kg/hour

Control Mode

PLC(Programmable Logic Controller Incinerator)

Combustion Chamber

970L

Internal Dimensions

120x90x90cm

Secondary Chamber

480L

Smoke Filter Chamber

Yes(Dry Scrubber)

Feed Mode

Manual

Voltage

220V-240V

Power

0.7Kw

Oil Consumption (kg/hour)

average 20.4

Gas Consumption (m3n/hour)

average 24.5

Temperature Monitor

Digital Display

Temperature Protection

Yes

Oil Tank

200L

Feed Door

100x80cm(Top Loading)

Chimney

10Meter

Chimney Type

Stainless Steel

1st. Chamber Temperature

800–1000

2nd. Chamber Temperature

1000-1200

Residency Time

2.0 Sec.

Gross Weight

7000kg

External Dimensions

260x150x180cm

This is a product specification of Poultry and dead fish

Incinerator Machine incinerator, ideal for the disposal of sheep, poultry and pet animal carcasses.

This incinerator should be designed for the incineration of:



・ Poultry carcasses

・ Larger sized pet animal carcasses

・ Farm shop and abattoir waste

・ Dead fish



Incinerator should be compact, fuel efficient and easy to run, designed to achieve its optimum incineration temperature quickly.








Fuel use options:

LPG or natural gas or diesel oil.


Mounting: -floor mounted



8.1 Factory Specifications

top-loading incinerator with a lift-opening lid, providing clear access for ease of manual or mechanical loading. All controls should be placed away from the loading area to avoid damage by loading machinery. Burn program should be available and the incinerator should be left unattended until the carcass reduces to ash.

It should be highly efficient, utilizing automatic high heat-rate burners, low thermal mass linings and timer controls that ensure minimal running costs; a thermostat triggers burner shut-off when optimum temperatures are reached, increasing fuel efficiency significantly.

Burn rate should be up to 50-100kg per hour , 220-240-volt electricity & fuel supply. A comprehensive operating, care & maintenance manual should be provided with each incinerator.



Chamber Volume  0.97m3

Load Capacity Up to 400kg

Load Method Top

Fuel Options diesel oil or natural gas or lpg type

Odour control should be provided with the incinerator, dry scrubber. Wet scrubber optional.
