30kgs rate 60kgs feed oil and gas burner small waste incinerator

30kgs rate 60kgs feed oil and gas burner small waste incinerator for Afghanistan

Machine Working mode

Oil or Gas + Power

Voltage

220V

Oil consumption (lit/hour)

Average 13.3lit/hour/chamber

Gas consumption (NG) (m3/hour)

16.0 (m3/hour) (NG)

Gas consumption (LPG) (m3/hour)

11.7 (m3/hour) (LPG)

Burning rate

Average 30kg/hour

Feed mode

Manual

Primary Combustion chamber

360 Liters

Secondary Combustion chamber

200 Liters

Combustion Chamber Material

Refractory Concrete Cement+firebrick

Internal dimensions

Yes (Primary chamber)

External dimensions

210x120x210cm(without chimney)

Door opening

48X60 cm

Fuel Type

Diesel Oil/ Natural Gas /LPG

Burner

Original

Chimney length

13.0 Meters

Smoke filter chamber

Yes

Temperature monitor

Two figure Digital Display

Temperature protection

Yes

Oil tank

200L

Burning Efficiency

>98%

Chimney type

Stainless steel

1st. chamber temperature

800c1000c

2nd.chamber temperature

1000c1200c

Residency time

2.0 sec.

Gross weight

4000kg

Electrical Plastic and glasses Shredder

Yes

Scrubber

Yes

Warranty Period

1.year

Primary combustion chamber

Yes

Secondary combustion chamber

Yes

Incinerator control case

S. steel

Incinerator chimney

Original

Fuel Burner

Yes

Oil Tank capacity

Yes

Oil Stand support

Yes

Dry Smoke Filter Chamber

Yes

Air Fan

Yes

Total waste incineration capacity/time

Minimum 60KG

for Ministry of Public Health, Kabul, Afghanistan

animal incinerator for poultry usage
burning rate around 150 kg/hr
load capacity around 350 kg .
Municipal waste incinerator for waste production rate of 50 ton/day
Medical waste incinerator for waste production rate of 200 kg/day
Medical waste incinerator for waste production rate of 500 kg/day
Medium Unit – to handle an average waste production of 500 kg/day and meet the capacity
Automatic PLC controller incinerator plant with Dual heat burners and dual chamber.
Burning capacity up to 30 Kg per hour.
Water showering cyclone air cleaner
Stain less steel 304 grade sheet for water scrub chamber
Time up to 250 mints.
Fully automatic electric control circuit with timers
Primary temperature up to 850 deg C
Secondary temperature up to 1100 deg C
Manual/automatic loading /unloading
Automatic start at power fail during process
Fast temperature rise control automatic detects fast burning materials and save burner fuel consumption by turn off /on burner automatically.
Suitable for waste of hospitals
Number of burner   2 Nos
Voltage  440 V 50 Hz
Operational enjoinment          5 C 60 C Humidity 10 C 90%
Fuel type               Natural gas Number of chamber      02 Nos
